13. Legal Information & Datasheet

This product complies with the requirements of European Directives 2006/95/EC, 2004/108/EC and 1999/5/EC.

Europe – EU Declaration of Conformity

https://www.geniushub.co.uk/img/confluence/manuals/ce-marking-logo.png

A copy of the EU Declaration of Conformity is available on request from Heat Genius Ltd, 41 Hylton Street, Birmingham, B18 6HJ. Email: support@geniushub.co.uk

UK – Declaration of Conformity

https://www.geniushub.co.uk/img/confluence/manuals/UKCA-black-fill.png

A copy of the UK Declaration of Conformity is available on request from Heat Genius Ltd, 41 Hylton Street, Birmingham, B18 6HJ. Email: support@geniushub.co.uk

Disposal Information

https://www.geniushub.co.uk/img/confluence/manuals/WEEE.png

The symbol above means that, according to local laws and regulations, your product should be disposed of separately from household waste. When this product reaches the end of its life, take it to a collection point designated by your local authority. Some collection points accept products for free. Collecting and recycling your product separately when you dispose of it helps conserve natural resources and ensures it is recycled in a way that protects human health and the environment.

An important note

Please read this manual carefully, as well as the safety information provided with the product, before you use the Genius Hub.

You can find out more about the product, including installation information, on our website: www.geniushub.co.uk

Your Genius Hub comes with 90 days of technical support and a 2-year manufacturer's warranty covering manufacturing defects.

If you have any problems with this product, please book a call with us through our website, www.geniushub.co.uk, or submit a Bug Report from the app.

Heat Genius Ltd, 41 Hylton Street, Birmingham, B18 6HJ
Email: support@geniushub.co.uk
Website: www.geniushub.co.uk

TM and © 2013–2026. All rights reserved. Designed by Heat Genius in the UK. Manufactured in the UK.

Heat Genius is a trademark of Heat Genius Ltd, registered in the UK.

Datasheet

Full specifications can be downloaded from: https://www.geniushub.co.uk/wiring

Operating environment: operating Genius devices outside these ranges may affect performance.

  • Transmission Frequency: 868.42MHz (EU) (unless otherwise stated)

  • Relative humidity: 10% to 85% (non-condensing)

  • Operating altitude: 0 to 3,048 metres (0 to 10,000 feet)

  • Indoor use only

  • RoHS compliant

Genius Hub (PH-HUB-C) specifications:

  • Line Voltage & Frequency: 230V AC, 50–60Hz, single phase

  • USB Line Voltage: 5V DC, Current: 2A max. (10W)

  • Regulation: EN 55022:2010 + AC:2011, EN 55024:2010, EN 61000-3-2:2006+A2:2009, EN 61000-3-3:2013

Communications Adapter specifications:

  • Connection: 5V DC (USB)

  • Transmission Frequency: 2.4GHz

  • Enclosure Protection: IP20

  • Chipset: SiLabs EFR32MG1 (IEEE 802.15.4)

Single Channel Receiver (HO-SCR-C) specifications:

  • Line Voltage & Frequency: 230V AC, 50–60Hz, single phase

  • Contact Type: Micro disconnection, voltage free

  • Contact Rating: 3(1)A 230V AC max.

  • Rated impulse voltage: CAT 2 – 2500V

  • Enclosure Protection: IP30

  • Regulation: EMC 2004/108/EC, R&TTE 1999/5/EC, LVD 2006/95/EC

Dual Channel Receiver (HO-DCR-C) specifications:

  • Line Voltage & Frequency: 230V AC, 50–60Hz, single phase

  • Contact Rating: 3(1)A 230V AC max.

  • Rated impulse voltage: CAT 2 – 2500V

  • Enclosure Protection: IP30

  • Regulation: EMC 2004/108/EC, R&TTE 1999/5/EC, LVD 2006/95/EC

Electric Switch (HO-ESW-D) specifications:

  • Line Voltage & Frequency: 230V AC, 50–60Hz, single phase

  • Resistive Load: 13A (3000W)

  • Inductive Load: 3A (750W)

  • Contact Type: Micro disconnection

  • Rated impulse voltage: CAT 2 – 2500V

  • Enclosure Protection: IP30

  • Regulation: EN 60730-2-7, CE, R&TTE, ETSI EN 300 220-2, ETSI EN 301 489-3

Smart Plug, dual-band (PH-PLG-E) specifications:

  • Line Voltage & Frequency: 230V AC, 50–60Hz, single phase

  • Transmission Frequency: 2.4GHz & 868.42MHz (EU)

  • Resistive Load: 13A (3000W)

  • Incandescent Load: 6A (1500W)

  • Fluorescent Load: 1A (320W)

  • Load Return Error Rate 5W–40W: ±3W

  • Load Return Error Rate 40W–3150W: ±5%

  • Overload: 3300W

  • Regulation: LVD: EN 61058; R&TTE: EN 301 489; EN 300 220

Wireless Room Thermostat (HI-WRT-D) specifications:

  • Power Supply: 3 x AA alkaline batteries

  • Temperature Range: 5°C – 30°C

  • Enclosure Protection: IP21

  • Regulation: EN 62479:2010, EN 62368-1:2014+A11:2017

Wireless Radiator Valve (DA-WRV-E) specifications:

  • Power Supply: 2 x AA alkaline batteries

  • Transmission Frequency: 2.4GHz

  • Maximum Water Temperature: 90°C

  • Noise Level: <30dBA

  • Max Spindle Movement: 2mm

  • Enclosure Protection: IP20

Wireless Room Sensor (PH-WRS-B) specifications:

  • Power Supply: CR123A lithium battery (1500mAh)

  • Field of view: 175° left to right, 40° up and down

  • Range: Front = 10m, ±45° = 8m

  • Regulation: EN 60950-1:2006, A11:2009, FCC part 15.249, EN 300 220-1

Wireless Motion Sensor (PH-WMS-B) specifications:

  • Power Supply: CR123A lithium battery (1500mAh)

  • Detection Range: Front = 10m, ±45° = 6m

  • Regulation: EN 60950-1:2006, A11:2009, FCC part 15.249, EN 300 220-1

Electric Relay (PH-ERS-A) specifications:

  • Line Voltage & Frequency: 230V AC, 50–60Hz, single phase

  • Contact Type: Micro disconnection

  • Resistive Load: 10A (2400W)

  • Regulation: FCC part 15.249, EN 300 220-1, NCC

Powered Room Thermostat (HI-PRT-A) specifications:

  • Line Voltage & Frequency: 230V AC, 50–60Hz, single phase

  • Contact Type: Micro disconnection

  • Resistive Load: 16A (3600W)

  • Inductive Load: 3A (750W)

  • Enclosure Protection: IP21
